ACL H Race Main Bearings 0.025mm B16A B17A B18A B18B C1 C5 B20B B20Z K

ACL Race Main Bearings are the perfect bearing upgrade when building an engine. Whether you are building a record-breaking dyno crusher or just rebuilding your daily driver's engine, ACL Bearings are cost effective and dependable.

The -.025mm on the end of this part number means that the bearing is thicker than a standard bearing. Machine shops will sometimes request these to get the bearing clearance perfect.
ACL Race Series Performance Engine Bearings

The unique combination of design, metallurgy and engineering come together to deliver what drivers expect from high performance Trimetal engine bearings. Designed to withstand higher RPM conditions

Features:

• High strength overlay plate with reduced thickness for improved fatigue properties
• Hardened steel backs on all rod bearings to improve the support of the bearing lining and assist with bearing retention in the housing.
• Increased crush for improved bearing retention
• Elimination of flash plating on the back of the bearings to improve heat transfer through the bearings and to maximize the grip between the bearings and its housing.
• Increased eccentricity to compensate for bore distortion at high rpm and to assist in the formation of hydrodynamic oil films.
• 3/4 grooved Main Bearings to optimize bearing load carrying surface area and oil flow to the conrod bearings.
• Tight consistent wall tolerances to help you maintain consistent clearances.
• Enlarged ID chamfers on bearing edges where required to accommodate large fillet radius on performance crankshafts.
