King Bearings XP STDX Main Bearings B16A B17A B18A B18B C1 C5 B20B B20

King Bearings XP STDX Main Bearings B16A B17A B18A B18B C1 C5 B20B B20Z K20A2 A3 Z1 A1 K24A2 A4 A8
King Bearings XP STDX Main Bearings B16A B17A B18A B18B C1 C5 B20B B20Z K20A2 A3 Z1 A1 K24A2 A4 A8

King Bearings XP STDX Main Bearings B16A B17A B18A B18B C1 C5 B20B B20Z K20A2 A3 Z1 A1 K24A2 A4 A8

$112.52

  • Brand: King
  • Availability: 1 In Stock
  • SKU: MB5259XPSTDX

Description: HONDA A-series, B-series, K-series Bearing Types:  MB - Main bearing set CR - Con Rod bearing set CS - Camshaft bearing set TW - Thrust washer set Material construction:  HP - Bi-metal aluminum Silicon Alloy XP - Tri-metal copper lead Bearing Features:   N - Narrowed D - Dowel Bearing size inches  Dimension / Under Size e.g. "STD" for...

Description: HONDA A-series, B-series, K-series

Bearing Types:

MB - Main bearing set

CR - Con Rod bearing set

CS - Camshaft bearing set

TW - Thrust washer set

Material construction:

HP - Bi-metal aluminum Silicon Alloy

XP - Tri-metal copper lead

Bearing Features:

N - Narrowed

D - Dowel

Bearing size inches

Dimension / Under Size e.g. "STD" for Standard, X equals .001" extra Clearance

Bearing Size Inches STDX STD .001" 010X .010" .011" 020X .020" .021" .030"
Bearing Size metric STDX STD .025   .25     0.5   0.75
Crankshaft undersize 0 0 0 -.010" -.010" -.010" -.020" -.020" -.020" -.030"
Additional Shell Thickness (on nominal) -.0005" 0 +.0005" +.0045" +.005" +.0055" +.0095" +.010" +.0105" +.015"



Metal Structure : Tri-metal copper lead.

Race Type: Circle track, Off-road, off-shore, others that require steel crankshafts.

Engine requirements: High load - Long Duration.

HIGHER LOAD CAPACITY
The only bearing with load capacity of 17,000psi in the intermediate and 10,200psi in the overlay
BETTER FATIGUE RESISTANCE
The only bearing that goes through a hardening process creating a black fatigue resistance shield, which makes the overlay 24% stronger than any other bearing (11.5hv vs 14.5hv)
MORE ACCURACY
The only bearings with wall thickness variation of ±.0001” as a standard in comparison to ±0.00025”.
MORE CONSISTENCY
from bearing to bearing, requiring less adjustment during assembly
ONE SET FITMENT
The only bearings that don’t require you to buy multiple sets to achieve desired oil clearance
